Fully Automatic Solar Panel / Module Cleaning Robot Manufacturer
Solar Panel Cleaner, Automatic Solar Module Cleaning Robot, Solar panel Cleaning system Manufacturer, Exporter in India
ReBot, self - powered module cleaning robot is designed to clean with a specially designed non - contact dust blowing mechanism. Thus ensuring increased output and protection of your solar power plant.
Technical Data Sheet
| Specification | ReBot |
|---|---|
| Robot Length | 4m |
| Battery type | Lithium Ion |
| Motor | 24V DC |
| Charging Type | Solar |
| Docking station | Inline with table on the side |
| Running Speed | 12m/min |
| Running km (to & fro) | Can be designed as per plant layout. Only the battery capacity and charging solar panel size needs to be modified according to the length of the table. |
| Dimension and Weight | L:4/6m W: 0.6 m H:0.2m Wt:40 kg |
| Sensors | Proximity/ Limit switches |
| Cleaning Method: Dry / Wet | Dry |
| Mode : Contact/ Contactless type | Contactless |
| Communication | Wireless LAN on-field with cloud based remote monitoring backend |
| Control | PLC based |
| Operating Temperature | 0-55 deg C |
| Own Software | Rockwell Automation/ Amazon Cloud |
| SCADA integration | Yes |
| Allowable max Table tilt | All table tilts are suitable |
| Allowable row tilt | upto 15deg |
| Warranty | 1 year |
| Product Life | 10 years or depending on AMC |
| Support/Facility in India | All design, manufacturing and service support is done in Mumbai, India |
| Fix/ Tracker | Both possible. For tracker docking station and time of cleaning cycle has to be considered. |
